Ok looking @ my new loom i got a little while ago whot is on the ECU side of the wiring loom

I hate wiring
Loom


BUT where do i start



Spaghetti junction map's are great fun

What you done with the old loom?



Its still on the car atm so will be following the old one removing it 1 by 1 and putting the new one on as i go but theres some wires as you might see that have know ends on i have abit of an idea where they go but its bloody hard ork for me

Need Ryans Advise i think Whot i need to know is one of the wires of this loom run to the fuel pump It says theres a wire and i have found the one its on about by the colour chart

But i can find the one that sayis it goes to the battery (i have a thick ish wire but does'nt have the coulours on it that its says on the paper work) they may have just forgot to put the colour makers on it ???

And where does the one go to that they say TO THE TACHO
Im trying to picture whot goies where in my head before i start it



Sorry cant help mate, im confused just looking at the pic

If your tossing the old loom. . one mans scrap is another mans gold etc



Ever things for sale m8
