Default Water in the footwell when heavy rain

My passenger side footwell seems to fill with water whenever there is bad rain. I'm assuming its that the passenger door never seems to shut completely, presumably it is hung wrong. But there is no water gathering in the door itself, only the footwell. Are there any seals or places i can check?
If you were logged in, you wouldn't be seeing this ad!
Register your free account today, or log in if you already have an account.
__________________
S2Steve is offline   Reply With Quote
Old 26-05-2008, 09:46 PM   #2
orion_crazy_carl
orion=mini saff

Trader Score: (3)
Join Date: Jun 2003
Location: suffolk Drives:orion mk2 zetec
Posts: 3,505
Thanks: 0
Thanked 0 Times in 0 Posts
Send a message via MSN to orion_crazy_carl Send a message via Yahoo to orion_crazy_carl
Default

normally a rotten batt tray mate,check towards the front of the foot well
__________________

WE HAVE ZE-TEC-NOLOGY!
Quote:
Originally Posted by Smartdj. View Post
....u cant comment u dont have an inlet
orion_crazy_carl is offline   Reply With Quote
Old 26-05-2008, 09:47 PM   #3
Dal_
Advanced PassionFord User

Dal_'s Avatar

Trader Score: (2)
Join Date: Nov 2006
Location: Northants
Posts: 2,206
Thanked 0 Times in 0 Posts
Puma_dal
Send a message via MSN to Dal_
Default

Check if there is a gromet in the bulkhead with your cars wiring loom going through it and if it's missing / perished / buggered.

__________________
http://www.projectpuma.com
Dal_ is offline   Reply With Quote
Old 26-05-2008, 10:14 PM   #4
NEWTON
Advanced PassionFord User

Trader Score: (0)
Join Date: Dec 2005
Location: under the bonnet
Posts: 1,566
Thanks: 0
Thanked 0 Times in 0 Posts
Default

Quote:
Originally Posted by orion_crazy_carl View Post
normally a rotten batt tray mate,check towards the front of the foot well
agreed
NEWTON is offline   Reply With Quote
Old 27-05-2008, 12:39 AM   #5
Micky
Advanced PassionFord User

Trader Score: (0)
Join Date: Jun 2003
Location: Dublin,IRELAND
Posts: 1,979
Thanks: 0
Thanked 0 Times in 0 Posts
Default

Or the bottom passenger side corner of the windscreen rotten to hell!!!Very common.Regards,Micky
__________________

Engine built & live mapped by Norris Motorsport 01773 836274
For proper brake's and suspension kits,TCA's,Calipers,Disc's,Adj Topmounts,Compression Struts etc use COMPBRAKE,call Tony on 07770 210881
Micky is offline   Reply With Quote
Old 27-05-2008, 12:56 AM   #6
vinnyvangough
Advanced PassionFord User

Trader Score: (0)
Join Date: Aug 2007
Location: Holsworthy, Devon
Posts: 2,218
Thanks: 0
Thanked 0 Times in 0 Posts
Send a message via MSN to vinnyvangough
Default

Yea usually the batt tray, my van got water inside, sorted the tray and replaced the gromit and it never got wet again
__________________
vinnyvangough is offline   Reply With Quote
Old 27-05-2008, 01:01 AM   #7
Ade
Fast Ford snapper

Ade's Avatar

Trader Score: (0)
Join Date: May 2005
Location: Glasgow
Posts: 2,589
Thanks: 0
Thanked 2 Times in 2 Posts
Default

They rust bad at the fusebox too.

Also my left hooker leaked even though there was no rust.... windscreen seal was perished and letting it in!
__________________

Cossie updates in Fast Ford magazine's 'Fast Fleet' every month
Ade is offline   Reply With Quote
Old 27-05-2008, 11:05 AM   #8
S2Steve
PassionFord Regular

Trader Score: (0)
Join Date: Oct 2007
Location: Staffordshire
Posts: 439
Thanks: 0
Thanked 0 Times in 0 Posts
Default

My car has no rust though!
__________________
S2Steve is offline   Reply With Quote
Old 27-05-2008, 11:38 AM   #9
Ade
Fast Ford snapper

Ade's Avatar

Trader Score: (0)
Join Date: May 2005
Location: Glasgow
Posts: 2,589
Thanks: 0
Thanked 2 Times in 2 Posts
Default

Get the capet up and have a hunt about for a point of entry whilst someone else hoses water over the car
__________________

Cossie updates in Fast Ford magazine's 'Fast Fleet' every month
Ade is offline   Reply With Quote
Old 27-05-2008, 11:47 AM   #10
dunketh
Chief Iron Oxide Farmer.

dunketh's Avatar

Trader Score: (0)
Join Date: Apr 2008
Location: Portland
Posts: 1,319
Thanks: 0
Thanked 0 Times in 0 Posts
Default

I get the same problem in the drivers footwell.
Again, no rust under the bonnet anywhere, perfect screen seals and perfect door fit with all rubber stuff as new and intact.
Sunroof drains are working and the sill drains are clear and dont collect water.

Its doing my head in. However, if I run my hand up behind the front wing drip panel I can feel a hole, hidden from view and easily missed by MOT testers and the like.
I'm 'assuming' this is the entry point but I wont know til I've found a way of fixing it without cutting a wing off! (possibly reach from the inside behind the speaker pod?).

I had a mk3 that rotted in the same place (behind drip panels) and had no battery tray or fusebox tray to speak of. Good old Ford and their built-in water traps.
__________________
dunketh is offline   Reply With Quote
Old 27-05-2008, 01:06 PM   #11
Kevin_Mc
Too many posts.. I need a life!!

Kevin_Mc's Avatar

Trader Score: (0)
Join Date: Apr 2007
Location: Glasgow
Posts: 794
Thanks: 0
Thanked 0 Times in 0 Posts
Send a message via MSN to Kevin_Mc
Default

i get the same problem aswell but its the perished rubbers for me
Kevin_Mc is offline   Reply With Quote
Old 27-05-2008, 01:42 PM   #12
orion_crazy_carl
orion=mini saff

Trader Score: (3)
Join Date: Jun 2003
Location: suffolk Drives:orion mk2 zetec
Posts: 3,505
Thanks: 0
Thanked 0 Times in 0 Posts
Send a message via MSN to orion_crazy_carl Send a message via Yahoo to orion_crazy_carl
Default

sunroof aswell,can cause tht
__________________

WE HAVE ZE-TEC-NOLOGY!
Quote:
Originally Posted by Smartdj. View Post
....u cant comment u dont have an inlet
orion_crazy_carl is offline   Reply With Quote
Old 27-05-2008, 04:47 PM   #13
Twins
15K+ Super Poster!!

Trader Score: (18)
Join Date: Sep 2004
Location: ESSEX
Posts: 17,472
Thanks: 0
Thanked 0 Times in 0 Posts
Default

Check the sunroof drain tubes that go down in the a pillers
__________________

My carbon clad s2
Twins is offline   Reply With Quote
Old 27-05-2008, 05:50 PM   #14
fatmike
Too many posts.. I need a life!!

Trader Score: (4)
Join Date: Apr 2006
Location: isle of wight
Posts: 809
Thanks: 0
Thanked 0 Times in 0 Posts
Default

lol I'll never forget, was out once in probably one of the heaviest downpours I've seen, and it started whilst I was out driving. I was in my RS turbo and the damn thing was more like a swimming pool by the end of the journey lol. It was mainly coming in the sunroof, there was tonnes of it. My mate rammed his jacket up inside the sunroof cover to try and soak it up lol. Rs turbos..... Not made for heavy rain!!
fatmike is offline   Reply With Quote
Old 27-05-2008, 08:21 PM   #15
OLDSKOOLRYAN
Regular Contributor

Trader Score: (0)
Join Date: Dec 2005
Location: Bolton, lancashire
Posts: 339
Thanks: 0
Thanked 0 Times in 0 Posts
Default

mine was the same, turned out to be corner of windscreen.
__________________
sigg removed my mod team no trade advertising unless you pay the fees
OLDSKOOLRYAN is offline   Reply With Quote
Old 27-05-2008, 09:42 PM   #16
marky_g
Fleet Manager

marky_g's Avatar

Trader Score: (0)
Join Date: Aug 2004
Location: Thurrock Essex
Posts: 5,878
Thanks: 0
Thanked 0 Times in 0 Posts
Send a message via MSN to marky_g
Default

Quote:
Originally Posted by dunketh View Post
I get the same problem in the drivers footwell.
Again, no rust under the bonnet anywhere, perfect screen seals and perfect door fit with all rubber stuff as new and intact.
Sunroof drains are working and the sill drains are clear and dont collect water.

Its doing my head in. However, if I run my hand up behind the front wing drip panel I can feel a hole, hidden from view and easily missed by MOT testers and the like.
I'm 'assuming' this is the entry point but I wont know til I've found a way of fixing it without cutting a wing off! (possibly reach from the inside behind the speaker pod?).

I had a mk3 that rotted in the same place (behind drip panels) and had no battery tray or fusebox tray to speak of. Good old Ford and their built-in water traps.
i have same problem, i always though there was a hole there only my xr3i dose it not my rst a orion mk2 or a 1300 bonus i had

i remember once my mum sayin years and years ago it was on TOP GEAR as new that there is a place they all leak some went back to fords for recall, i gotta find it this year get my floor is rotten..........sorta dont wanna know whats under there
__________________
XR3i+

Last edited by marky_g; 27-05-2008 at 09:44 PM..
marky_g is offline   Reply With Quote
Old 28-05-2008, 11:43 AM   #17
kurdt5
Too many posts.. I need a life!!

kurdt5's Avatar

Trader Score: (0)
Join Date: Oct 2004
Location: dorset
Posts: 702
Thanks: 0
Thanked 0 Times in 0 Posts
series1rs
Default

Quote:
Originally Posted by dentmaster View Post
mine was the same, turned out to be corner of windscreen.
I have had water in the footwell, driving me nuts over last 2 months....problem?

The passenger window seal slightly tilted outwards by the wing mirror....water ran towards the wingmirror on the tilt into the door, dripped down inside the door card cleared the bottom door seal and saoked my car....

Fixed with a £13 window seal from FORD.

Click the image to open in full size.

Click the image to open in full size.

Click the image to open in full size.
kurdt5 is offline   Reply With Quote
Old 28-05-2008, 06:45 PM   #18
ricky_2006
I've found that life I needed.. It's HERE!!

Trader Score: (0)
Join Date: Oct 2007
Posts: 1,080
Thanks: 0
Thanked 0 Times in 0 Posts
Default

i have same problem when it heavily rains but its in the back footwells. so fukin annoying. havent got a clue where it could be cumin from?????????????????????
ricky_2006 is offline   Reply With Quote
Old 28-05-2008, 09:00 PM   #19
Zetecfiesta
PassionFord Post Whore!!

Trader Score: (0)
Join Date: Jan 2005
Location: Westhoughton Bolton
Posts: 4,181
Thanks: 0
Thanked 0 Times in 0 Posts
Send a message via MSN to Zetecfiesta
Default

back could be boot seals or rear window seals!
Zetecfiesta is offline   Reply With Quote
Old 06-05-2010, 08:33 PM   #20
steve escort rs
Virgin

Trader Score: (0)
Join Date: May 2010
Location: leamington spa warwickshire
Posts: 7
Thanks: 0
Thanked 0 Times in 0 Posts
Default

Quote:
Originally Posted by Ade View Post
They rust bad at the fusebox too.

Also my left hooker leaked even though there was no rust.... windscreen seal was perished and letting it in!
thats what it will be under the windscreen seal i got same prob now its rusred under seal but u cant see it
steve escort rs is offline   Reply With Quote
Old 06-05-2010, 08:38 PM   #21
Fordmad!
PassionFord Post Troll

Trader Score: (0)
Join Date: Apr 2010
Location: Ellesmere
Posts: 3,284
Thanks: 0
Thanked 0 Times in 0 Posts
Default

Check the rear lights, my xr3i cabby was the same leaked through the lights down under the back seats into the footwells!!!
Fordmad! is online now   Reply With Quote
Old 06-05-2010, 08:48 PM   #22
Karlos G
Balls Deep!

Karlos G's Avatar

Trader Score: (4)
Join Date: Jan 2007
Location: Suffolk
Posts: 8,894
Thanks: 0
Thanked 3 Times in 3 Posts
Default

2008
__________________
.....
Karlos G is online now   Reply With Quote
Old 06-05-2010, 09:07 PM   #23
12_Second_rst
Too many posts.. I need a life!!

12_Second_rst's Avatar

Trader Score: (1)
Join Date: May 2010
Location: U.K
Posts: 680
Thanks: 0
Thanked 0 Times in 0 Posts
Default

Bet it's rotton now if he never found the leak lol
12_Second_rst is offline   Reply With Quote
Old 06-05-2010, 09:15 PM   #24
makaveli96
Advanced PassionFord User

makaveli96's Avatar

Trader Score: (0)
Join Date: Sep 2006
Location: Bedfordshire
Posts: 1,630
Thanks: 0
Thanked 0 Times in 0 Posts
Default

It must be behind the battery tray some where as I had this problem once.
__________________

186bhp with 205ft at 15psi
Italy World Cup Winners 34* 38* 82* 06*
makaveli96 is offline   Reply With Quote
Old 06-05-2010, 09:29 PM   #25
Karlos G
Balls Deep!

Karlos G's Avatar

Trader Score: (4)
Join Date: Jan 2007
Location: Suffolk
Posts: 8,894
Thanks: 0
Thanked 3 Times in 3 Posts
Default

Quote:
Originally Posted by 12_Second_rst View Post
Bet it's rotton now if he never found the leak lol
lol
__________________
.....
Karlos G is online now   Reply With Quote
Old 06-05-2010, 09:31 PM   #26
marky_g
Fleet Manager

marky_g's Avatar

Trader Score: (0)
Join Date: Aug 2004
Location: Thurrock Essex
Posts: 5,878
Thanks: 0
Thanked 0 Times in 0 Posts
Send a message via MSN to marky_g
Default

turned out mines a hole in the fuse box
__________________
XR3i+
marky_g is offline   Reply With Quote
Old 06-05-2010, 10:50 PM   #27
Korda
Too many posts.. I need a life!!

Korda's Avatar

Trader Score: (1)
Join Date: Sep 2008
Location: Devon
Posts: 907
Thanks: 0
Thanked 0 Times in 0 Posts
Default

its a ford lol
Korda is offline   Reply With Quote
Old 07-05-2010, 07:40 PM   #28
ste45
Regular Contributor

ste45's Avatar

Trader Score: (0)
Join Date: Dec 2007
Location: warrington
Posts: 300
Thanks: 0
Thanked 0 Times in 0 Posts
Default

had this problem last year turned out to be the seal under the fuse box , bit of silicon around the seal and its bin dry ever since
ste45 is offline   Reply With Quote
Old 09-06-2011, 10:24 AM   #29
colin135
freeone

Trader Score: (0)
Join Date: Aug 2010
Location: essex ss25ae
Posts: 4
Thanks: 0
Thanked 0 Times in 0 Posts
Default

Quote:
Originally Posted by ste45 View Post
had this problem last year turned out to be the seal under the fuse box , bit of silicon around the seal and its bin dry ever since
Common problem apparently with mk3/mk4 escorts like somebody has said already the silicone or original sealant around or under the f/box has perished.Ive sorted mine now with new sealant and all appears ok.But mine must have gone unnoticed cos i had to weld a small bit metal to cover hole.Atb Colin135.
colin135 is offline   Reply With Quote
Old 09-06-2011, 10:50 AM   #30
s2turbsZVH
Will it ever end !!!!!!!

Trader Score: (0)
Join Date: Jun 2007
Location: Colchester, Essex
Posts: 460
Thanks: 0
Thanked 0 Times in 0 Posts
Default

2008 !! the car will be a coke can by now lol

Last edited by s2turbsZVH; 12-06-2011 at 07:08 PM..
s2turbsZVH is offline   Reply With Quote
Old 11-06-2011, 01:31 AM   #31
PETEDUDE007
PassionFord Regular

Trader Score: (0)
Join Date: Jun 2010
Location: Aberdeen
Posts: 488
Thanks: 0
Thanked 0 Times in 0 Posts
Default

Quote:
Originally Posted by karlos g View Post
2008

gotta love it!
__________________
PETEDUDE007 is offline   Reply With Quote
Old 11-06-2011, 01:31 AM
PassionFord
Ford Focus




Paid Advertisement





submit to reddit
Reply

Tags
drain, dripping, escort, fiesta, foot, footwell, footwells, ford, leaking, location, mk4, passenger, puma, rain, tray, van, water, wet

Thread Tools Search this Thread
Search this Thread:

Advanced Search
Display Modes

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off
Trackbacks are Off
Pingbacks are Off
Refbacks are Off

Forum Jump

Similar Threads
Thread Thread Starter Forum Replies Last Post
Water in rear passenger footwell of 4x4 saph??? rog General Car Related Discussion. 13 10-04-2008 07:21 PM
water in footwell Mark_ Escort MK 5 / MK 6 7 07-01-2008 10:35 AM
WATER LEAKING INTO DRIVERS FOOTWELL / FORD PUMA???? simmonjane Technical help Q & A 6 29-06-2007 03:31 PM
WATER IN DRIVERS FOOTWELL/FORD PUMA simmonjane General Car Related Discussion. 4 01-06-2007 02:14 PM
Heavy Rain forecasted @ POD sunday. DOO General Car Related Discussion. 12 14-04-2005 04:29 PM

Advertising - Privacy Statement - Terms of Service - JOBS



All times are GMT. The time now is 08:42 PM.


This forum is owned and operated by Internet Brands, Inc., a Delaware corporation. It is not authorized or endorsed by the Ford Motor Company and is not affiliated with the Ford Motor Company or its related companies in any way. Ford® is a registered trademark of the Ford Motor Company.
